Multi-Gigabit Ethernet support
Even where a PoE-enabled switch is not in use, access points are reliably powered by the LANCOM PoE++ Injector thanks to multi-Gigabit Ethernet (up to 5 Gbps). Access points that are far away from a regular power outlet continue to offer full performance without loss.
Full power thanks to PoE, PoE+, and PoE++
As it supports the PoE standards IEEE 802.3af (PoE), IEEE m 802.3at (PoE+), and IEEE 802.3bt (PoE++), the Injector is the optimal choice for powering all of your LANCOM access points by means of Power over Ethernet. Even high-performance products operate without performance loss.
High output power
With power supplied as per IEEE 802.3af/at/bt with a guaranteed power output of 65W over up to 100m, the LANCOM PoE++ Injector gives you the flexibility to position your access points for perfect signal coverage.
Integrated power supply unitz
Thanks to the power supply unit integrated into the LANCOM PoE++ Injector, the IEC connector supplied with it is the only additional component you need—a space-saving solution.
Plug & play
The Injector works with a convenient plug & play installation for quick and easy integration into the network. Simply connect the LANCOM PoE++ Injector between the switch and the access point and use the power cord to supply electricity
Netzwerk
Ethernet Schnittstellen Typ: 5 Gigabit Ethernet
Ethernet LAN Datentransferraten: 10,100,1000,2500,5000 Mbit/s
Eigenschaft: Power over Ethernet (PoE)
Netzstandard: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Merkmale
Produktfarbe: Schwarz
Eigenschaft: Plug & Play
Energieschutzeigenschaften: Überstrom, Überspannung, Überhitzung, Überlastschutz, Kurzschluß
Anschlüsse und Schnittstellen
Anzahl Ethernet-LAN-Anschlüsse (RJ-45): 1
RJ-45-Eingangsanschlüsse: 1
RJ-45-Ausgangsanschlüsse: 1
Leistung
Power over Ethernet (PoE) Spannung: 56 V
Ausgangsleistung: 65 W
Netzteilfrequenz: 50/60 Hz
Eingangsspannung: 100 - 240 V
Power over Ethernet (PoE) Leistung pro Anschluss: 65 W
Betriebsbedingungen
Betriebstemperatur: -25 - 40 °C
Temperaturbereich bei Lagerung: -25 - 65 °C
Logistikdaten
Warentarifnummer (HS): 85044090
